SH-4158 48” Coating/Polishing Pan Machine Specification: Size: L2000mm x W1500mm x
48" coating pan 糖衣機
SH-4158 48” Coating/Polishing Pan Machine
Specification:
Size: L2000mm x W1500mm x H2500mm
Horsepower: 3HP
Weight: 250KG
Capacity: 100KG/Batch
Feature:
The standard machine is supply with a 48” diameter pan, but can also be supplied with either a larger capacity 60” or 70” diameter pan or a smaller type 24”, 38” and 42” pan either as an alternative or an additional unit. The pans are shaft-mounted and secured to the drive using only a single grub-screw and can therefore be quickly and easily removed or changed.
The pan can be rotated in either direction by simply activating a switch on the control panel. Hot or cold air blowers can be provided as an optional extra if required.
Item
Size
Number of Ribs
Horsepower
Capacity
Speed
1.
16”
6 ribs
120W
5-7KG
30RPM
2.
24”
4 or 6 ribs
1HP
10-20KG
30RPM
3.
38”
8 or 10 ribs
2HP
40KG
30RPM
4.
42”
8 or 10 ribs
2HP
60KG
25RPM
5.
48”
10 ribs
3HP
100KG
22RPM
6.
60”
12 ribs
5HP
120KG 來自:許OO商O 詢價 ***0777@gmail.com 來自:垛OO際OO公O 詢價 ***elt_tw@yahoo.com 來自:雙OO業OO公O 詢價 ***angyuan.ltd@gmail.com 精巧設計，擺放不占空間，LCD藍色背光，數據清晰，重量自動平均功能，增加準確度，JCQ 鈺恆計數秤|
