三角袋茶葉包裝機

YD-SJB01三角袋茶叶包装机Automatic nylon triangle tea bag packing machine

APPLICATIONS/适用于:

Be used for automatically packing products as green tea ,black tea,flower tea ,health tea,medicine tea,granule and so on .

适用于：绿茶、红茶、花茶、保健茶、中药茶、颗粒等。

Functions:

This unit can perform either three sides sealing and triangle teabag .just need single bond to change the bag between three sides sealing and triangle shape.

功能：1.用于平面包装、三角立体包装等产品，只需单键即可

    轻松切换平面包装、三角立体包装二种包装型式

2. packaging capacity :3000bags/h (Determined by packing material)

2．包装能力达3000袋/小时（实际能力根据物料特性而定）。

3.Applicable packing materials:Nylon film with thread and label.

3．该机器可使用带线带标签的包装卷膜。

4.The precision volumetric metering way very easily in the transformation of filling material. Electronic scale metering can be collocated according to the material.

4．精密转盘式计量下料方式可以很容易在变换填充物；根据物料特        性可配置电子称计量下料方式；

5.Human-Computer Interface，Omron PLC control,adopted thePanasonnic double Servo motor to make the bag .supplied complete setting functions.easy operating

5.触控人机面板，欧姆龙PLC控制器，采用松下双伺服马电机制袋，提供完整设定功能，可依照需求调整多项参数，提供使用者最大操作弹性。

6.Main motor overload protection device

6．主马达保护装置（循环超时）

7.Packaging material tension automatic adjustment device

7．包装材料张力自动调节装置

8.The machine will automatically stop when Issued the warning.

8.故障自动报警并自动停机。

四、技术参数/Technical data

项  目/item	内容/content
包装速度/capacity	30--50包/分钟具体视包装膜质量及物料的特性确定30-50bags/Min (Determined by packing material)
计量精度/Filling precision	≤±2%（取决包装原物料不同，而有差异）(Determined by packing material)
制袋尺寸/Bag size	60-80（W）*40-80（L）mm
包装膜宽/Packing film	120mm、140mm、160mm
制袋形式/sealing type	包装材料用卷膜，机器自动制袋为三角锥形袋及扁平袋
计量范围/Filling range	2-10ml（实际根据物料特性而定）
薄膜厚度/film thickness	0.04-0.06mm
包装材料/Packing material	尼龙、聚酯网布、无纺布、可超声波封口的材料 Nylon,Polyester netnon-woven fabrics,.ultrasonic sealing materials
放卷外径Rolled outer diameter	≤∮400mm
放卷纸芯内径Rolled paper core inside diameter	∮76mm
整套耗气量/air consumption	0.6Mpa 0.4m3/min
整套设备总功率/total power	2.2KW
电源/Power	单相/Single 220V   50HZ
空压机/air compressor	不小于1立方less than 1 cube
整套设备总高/Dimension	780× 940×1800㎜
